Skew

skew

The skew parameter shears an image, sliding one pair of edges past the other. It is the simplest way to fake a viewing angle, and it is the equivalent of the CSS skew() transform.

Syntax

skew takes two numbers in degrees, both required:

skew=x,y

The horizontal shear is applied first, then the vertical. A positive x moves the top edge to the right; a positive y moves the right edge down.

Original image
sandbox-demo
skew=20,15 shears on both axes
sandbox-demo
skew=25,0 moves the top edge right
sandbox-demo
skew=0,25 moves the right edge down
sandbox-demo

The parameter is ignored when either value has a magnitude of 89 degrees or more, when both are zero (skew=0,0), or when only one number is given.

Layer Forms

mark-skew and blend-skew shear a layer before it is placed on the base image, and both accept indexed spellings such as mark-skew[1].

Output

The area outside the sheared shape is transparent, and on a format without transparency it is filled with bg, or black when bg is unset. This differs from Cloudinary, which fills a shear margin with white.

For a true perspective warp rather than a shear, use distort.
